Matrix properties
number of rows	40,174
number of columns	40,174
nonzeros	281,662
# strongly connected comp.	1
explicit zero entries	0
nonzero pattern symmetry	symmetric
numeric value symmetry	symmetric
type	binary
structure	symmetric
Cholesky candidate?	no
positive definite?	no

author	C. Schultz
editor	H. Meyerhenke
date	2011
kind	random unweighted graph
2D/3D problem?	no

Notes:

DIMACS10 star-mixtures set

Each graph in this benchmark represents a star-like structure of
different graphs S0 , . . . , St. Graphs S1 , . . . , St are weakly
connected to the center S0 by random edges. The total number of edges
between each Si and S0 was less than 3% out of the total number of
edges in Si . The graphs are mixtures of the following structures:
social networks, finite-element graphs, VLSI chips, peer-to-peer
networks, and matrices from optimization solvers.

More info can be found in the paper I. Safro, P. Sanders, C. Schulz:
Advanced Coarsening Schemes for Graph Partitioning, SEA 2012.

Author: Christian Schulz, uploaded on March 30, 2012.
